M-15/15A
Specification:
|
Model |
M-12 |
M-12A |
|
Frequency Response |
60Hz-16KHz |
60Hz-16KHz |
|
Directivity Angle |
H60°×V40° |
H60°×V40° |
|
Impedance |
8 ohms |
8 ohms |
|
Long-term Power(RMS) |
600W |
600W |
|
Power Peak |
1200W/5Min |
1200W/5Min |
|
Sensitivity |
100dB |
100dB |
|
Maximum SPL |
131dB |
131dB |
|
Connection |
2×NL 4 speakon |
2×NL 4 speakon |
|
DimensionsH×W×D |
675×446×378.5mm |
675×446×378.5mm |
|
Low |
15 IN×1（380mm） |
15 IN×1（380mm） |
|
High |
3 IN×1（75mm） |
3 IN×1（75mm） |
|
N.W. |
21.3kg |
23kg |
| Power | AC 220V / 50Hz-60Hz |
