AU-48
AU-48
4 In - 8 Out Speaker Management System
AU-48 is a High End 4-IN/8-OUT digital speaker management system which maintains the same high quality hardware present in former AU-48 versions. Designed for maximum versatility, it provides all the processing and control necessary for both live and fixed installation use. Providing for any crossover configuration, it offers 4 analog inputs, 8 analog outputs and 2 digital S/PDIF inputs, managed by a powerful DSP Engine, for a full 96kHz processing, in addition to 24 bit AD/DA Converters. Each input channel provides a choice of EQ with 30-band Parametric EQ, Gain control, Noise Gate, RMS Compressor, Internal White/ Pink Noise Generator, and configurable Delay.Each output offers up to 11-band of parametric equalization, in addition to the crossover filters which themselves provide slopes from 6dB/Octave up to 48dB/Octave. Each output path also features Peak Limiter, RMS Compressor and configurable Delay. The AU-48 supports a full matrix mixing mode where inputs may be routed/mixed in any ratio to any output. For remote configuration and control the AU-48 can be connected via USB/RS485/TCP-IP connections. The control remote PC software allows simultaneous control up to 32 units, setting all parameters and showing real time levels. Frequency response: 20Hz-40kHz(±0.5dB)/Line
Power : 220 VAC
- LINK
